NGK AUDI R8 IGNITION COIL FOR 2.0 TFSI EA113 AND 2.0 TSI EA888.1 EA888.2 ENGINES

NGK ignition coil type AUDI R8 for 2.0 TFSI / TSI engines of the Audi Seat Skoda VW group, which can be found for example on the VW GOLF 5 Gti, AUDI S3 8P, VW GOLF 6 Gti, SEAT LEON CUPRA, SKODA OCTAVIA VRS, VW GOLF 6 Gti Edition 35 / 6R, POLO WRC, Golf 5 Gti Edition 30 …

Sold individually, they are installed in place of the original ignition coils on all 2.0 TFSI EA113 and 2.0 TSI EA888.1/2 engines.

If you have a check engine light, you have noticed misfires or the fault code relating to misfires such as (P0301 Cylinder 1 Misfire Detected, Ignition Coil Power Output, Ignition circuit Short, Ignition Coil A Primary/Secondary Random/Multiple Cylinder Misfire Detected …) replace your original coils with NGK coils!

• Brand: NGK
• Type: Ignition coil
• Color: Red
• Sold individually
• For 2.0 TFSI EA113, 2.0 TSI EA888.1 and 2.0 TSI EA888.2 engines
• Not compatible with 2.0 TSI EA888.3: VW GOLF 7 GTI, S3 8V…

DESCRIPTION

NGK red ignition coils are high-performance ignition coils for VAG 2.0 TFSI and 2.0 TSI engines. (2.0 TFSI EA113 / 2.0 TSI EA888.1 / 2.0 TSI EA888.2)

These are the ignition coils recommended by all tuners on this engine for their reliability and manufacturing quality.

When to Replace Ignition Coils

Whether it is a question of replacing the original ignition coils (simple maintenance), without any engine preparation, a stage 1, stage 2, stage 3 or even a Flex Fuel E85 conversion, replacing the ignition coils can only be beneficial for your engine.

In fact, there is no frequency announced by the VAG group concerning the replacement of ignition coils and they often cause problems as soon as the vehicle starts to have a high mileage.

NGK U5014 coils simply install in place of your original coils, without any modification on 2.0 TFSI EA113 / 2.0 TSI EA888.1 / 2.0 TSI EA888.2 engines.

NGK coils and engine preparation

Furthermore, knowing that ignition coils are a point that is often neglected, you should know that from the moment you are going to prepare your engine, in Stage 1, Stage 2 or even in Stage 3 or for a simple Flex Fuel E85 conversion, it remains important to pay attention to your coils.

We strongly recommend replacing the coils before performing any engine preparation, even a simple stage 1. When the engine reprogramming is in place, with the vehicle on the power bench, it would be a shame if an overly old coil prevented your tuner from being able to complete its adjustments and other control logs.

Finally, it is important to remember that the NGK RED AUDI R8 coils do not provide any “gain” in terms of power.

The purpose of replacing the coils is above all to make your engine's ignition more reliable.

Features

• Color: red
• ETKA VW Audi references: 06E905115F / 06E905115E
• NGK Reference: U5014
• Made in Japan

Alternative references:

• 06E905115E
• 06E905115F
• 06E905115G
• R0602S00300
• R0602S00300
• R0702S00300

Details

• Brand: NGK
• Type: Ignition coil
• Sold: individually

Compatibility

NGK R8 coils are the preferred coils for our 2.0 TFSI EA113 and 2.0 TSI EA888.1/2 engines.

Not compatible with EA888 GEN3 engines (GOLF 7 GTI, S3 8V, etc.)

Please note, if fitted to a 1.8T, installation of the spacers offered as an accessory is mandatory.
