Boost Cooler Stage 1 TD Power-Max methanol kit SNOWPERFORMANCE

Starter kit with 300psi (20.7bar) high pressure pump, adjustable turbo pressure sensor.
The operation is very simple: the system starts the injection once the pre-defined turbo pressure is reached and it injects a fixed quantity of liquid until the pressure sensor is triggered again.

Each kit comes standard with the 3L tank, which is a little small for turbodiesel engines.

V engines (eg Audi 3.0 TDI, Mercedes 3.0 CDI) require two injectors (also to be specified in the options)

Features

• Compatible with virtually all turbo diesel engines (TDI / HDI / TDCi / TDS / etc.)
• Provides torque and power gains of up to 15-25%
• Reduction of thermal load for engines in factory setting but especially for modified engines: reprogramming Stage1, Stage2, Stage3.
• Reduces exhaust gas temperature (EGT) by up to 120°C – ideal for making reprogrammed engines more reliable.
• No drop in turbo pressure as is often the case with large conventional air exchangers. Additional cooling of the charge air up to 60 °C is possible.
• Reduction of fuel consumption by up to 10-15%.
• Reduces pollution: less formation of nitrogen oxides (NOX) and carbon dioxide (CO2).
• Significantly reduces carbon formation in the combustion chamber and intake system.
• Easy installation

Functioning:

Compared to the Stage2 and Stage3 Kit, with this kit the injection quantity is not managed electronically. The pressure sensor is triggered and activates the pump, which in turn injects a fixed quantity of liquid. We recommend this kit on engines without too many load variations, such as fixed load engines (generators) and boat engines.
The use of this system in a car is possible, but for an effective adjustment we recommend the Stage2 or Stage3 system. With the Stage2 and Stage3 kit the amount of injected liquid is proportional to the engine load.

This kit includes:

• A 300psi high pressure pump
• 1 x Adjustable turbo pressure sensor with relay
• 2 x WMI Injector
• 1 x 3l tank
• 1 x Tank level sensor with LED indication
• 1 x 3 meters of 1/4″ rigid hose
• 1 x 1/4″ injector holder, 90° steel
• 1 x Accessories
• 1 x Installation Instructions (in English)
